Roof Curving Machine

Introduction
Roof curving machines are used to roll sheet metals into certain shapes so that these sheets can be used as roofing panels. This steel panel roll forming line is controlled with Panasonic PLC control system. Besides, the main motor of this roofing sheet making machine is from Yaskawa. Size of this machine is 3000 mm × 1400 mm × 1400 mm, the main motor power is 0.8 KW, the hydraulic power is 7.5 KW, and the maximum curving degree is 120°. Available sheet metals are with thickness of 0.27 mm to 0.8 mm. Cr12 is applied as materials of cutter blades, and chrome is coated on the surface. Hardness of the cutter blade is HRC58-62.

SUZHOU MANFENGXIANG TECHNOLOGY CO.,LTD. is a professional manufacturer and supplier of roof curving machines, slitting lines, cut to length line machines, pipe-making machines and related metal sheet processing equipments in China. They solve the problem of roof leakage that conventional machine is not able to be handled with. And this steel panel roll forming line is national inspection-exempted product from external supervision and sampling inspection.

Our roof curving machines, tube mills, roll forming machines and other products have been sold to more than 50 countries and regions, including Russia, France, England, Australia, America, Kazakhstan, Tajikistan, Malaysia, Nigeria, Romania and Albania. Our products have won acclaim from all customers at home and abroad. SUZHOU MANFENGXIANG TECHNOLOGY CO.,LTD. is always ready to provide the best solution for your production requirements.
